Aluminum building cladding
Thickness:1.5-5.0mm
Material:1100, 3003, 5005, 6063, etc
Surface treatment:PVDF/PE
Supply capacity:50000 ㎡/month
Service life:30-year warranty
Minimum Order Quantity (MOQ):30㎡
Color:RAL and other customized colors
Size Customized size
Feature:Durable, easy to install, environmentally friendly, high-quality
Certificate:CE，UL，SASO，ISO 12944-6
Delivery time:15-43 days
Installation Guide:Provide detailed construction drawings
Place of Origin:Guangdong, China
- Product Description
High-Performance Aluminum Building Cladding Solutions
Are you looking for durable, weather-resistant exterior protection for your next construction project? Aluminum building cladding offers the perfect combination of structural integrity and architectural flexibility. Our premium cladding systems provide superior protection against harsh weather conditions while enhancing your building's visual appeal. With advanced material technology and customizable design options, the product delivers long-lasting performance that outperforms traditional materials like wood or vinyl in demanding environments.
Why Choose Our Aluminum Cladding Systems?
Superior Material Engineering
Our cladding boards include high-grade aluminum amalgams counting 3003 and 5005 arrangement materials. These combinations provide extraordinary erosion resistance and formability. Board thickness ranges from 1.5mm to 5.0mm, guaranteeing ideal strength-to-weight proportions for your particular application needs.
The progressed PVDF and PE surface medicines give extraordinary toughness. Your boards will keep up their appearance and defensive qualities for decades. These coatings stand up to chalking, blurring, and natural corruption superior than customary wraps up.
All-Weather Performance
Your building deserves protection that works year-round. Our aluminum building cladding withstands extreme temperatures, heavy rainfall, and coastal salt spray. The material's inherent properties resist expansion and contraction issues that plague other cladding materials.
Wind resistance testing confirms our systems perform safely in conditions up to 150 mph. This makes them ideal for high-rise buildings and structures in hurricane-prone regions.
Energy Efficiency Benefits
Introducing our cladding frameworks can decrease your vitality costs altogether. The ventilated plan makes an protection discuss hole between boards and building structure. This warm break decreases warm exchange by up to 40% in extraordinary climates.
When combined with legitimate cover materials, your building envelope gets to be profoundly productive. Lower warming and cooling costs give long-term esteem that offsets introductory speculation.
Surface coating quality standards
|
Serial Number
|
Item
|
Standard Requirements
|
|
01
|
Appearance Quality
|
No cracks or weld breaks on either side of the aluminum material; no coating peeling or cracking. The appearance is clean and the color is basically consistent, with no obvious scratches. The decorative surface has no obvious indentations, marks, or unevenness. No obvious color changes; the coating has no flow marks, cracks, bubbles, inclusions, or other surface defects.
|
|
02
|
Film Thickness
|
Average film thickness ≥ 50μm, minimum local film thickness ≥ 34μm.
|
|
03
|
Gloss Deviation
|
Gloss range 31.0～33.9, average 32.0
|
|
04
|
Adhesion
|
Cross-cut test, grade 0
|
|
05
|
Hardness
|
≥2H
|
|
06
|
Acid Resistance
|
5% HCl, 24h, no change
|
|
07
|
Abrasion Resistance
|
6.6L/μm
|
|
08
|
Warranty Period
|
≥ 10 years
|
Customization and Design Flexibility
Color and Wrap up Options
Choose from RAL standard colors additionally boundless custom color coordinating. Our powder coating handle conveys dynamic, long-lasting wraps up that keep up their excellence for a long time. Anodized wraps up give metallic appearances with predominant scratch resistance.
Size and Configuration
Every venture has special necessities. We fabricate boards in customized measurements to minimize squander and guarantee culminate fit. Our designing group gives CAD 3D modeling and fabric mechanics reenactment for complex installations.
Professional Establishment Support
Precision Manufacturing
Our plant pre-assembly forms guarantee establishment precision inside 0.5mm resistances. This exactness decreases field alteration time and ensures proficient comes about. Nitty gritty development drawings go with each order.
Technical Guidance
On-site specialized bolster guarantees your establishment continues easily. Our experienced group gives direction all through the establishment handle. This comprehensive approach minimizes delays and guarantees ideal execution.
Quality Assurance and Certifications
International Standards
Our items meet thorough universal certification necessities counting CE, UL, SASO, and ISO 12944-6 benchmarks. These certifications affirm our commitment to quality and security over worldwide markets.
Performance Testing
Every bunch experiences comprehensive testing for grip, hardness, and climate resistance. Our coating frameworks surpass industry measures for solidness and appearance maintenance. Quality control forms guarantee steady execution over all items.
Environmental Sustainability
Recyclable Materials
Aluminum is 100% recyclable without quality corruption. Choosing our cladding frameworks underpins feasible development hones. End-of-life fabric recuperation diminishes natural affect compared to non-recyclable alternatives.
Long Benefit Life
Our 30-year guarantee reflects certainty in long-term execution. Negligible upkeep necessities decrease lifecycle natural affect. This solidness kills visit substitution cycles related with other materials.
Getting Started with Your Project
Ready to explore how aluminum building cladding can transform your next construction project? Our team provides comprehensive consultation from initial concept through final installation. Contact us at [email protected] to discuss your specific requirements and receive detailed project quotes.
