aluminum sheet metal wall panels
Thickness:1.5-5.0mm
Material:1100, 3003, 5005, 6063, etc
Surface treatment:PVDF/PE
Supply capacity:50000 ㎡/month
Service life:30-year warranty
Minimum Order Quantity (MOQ):30㎡
Color:RAL and other customized colors
Size Customized size
Feature:Durable, easy to install, environmentally friendly, high-quality
Certificate:CE，UL，SASO，ISO 12944-6
Delivery time:15-64 days
Installation Guide:Provide detailed construction drawings
Place of Origin:Guangdong, China
- Product Description
Aluminum Sheet Metal Wall Panels - Premium Architectural Cladding Solutions
Looking for durable, lightweight cladding for your next project? Our aluminum sheet metal wall panels deliver exceptional performance and aesthetic appeal. Manufactured from high-grade thin-gauge aluminum, these panels are expertly formed into specific profiles that balance flexibility with structural strength. Whether you're designing a modern warehouse, contemporary residence, or commercial building, these versatile panels offer the perfect blend of functionality and industrial elegance you need.
Superior Material Engineering
Our boards begin with premium aluminum combinations counting 1100, 3003, 5005, and 6063 grades. Each fabric brings interesting properties to your venture. The 3003 combination offers amazing formability, whereas 5005 gives upgraded erosion resistance for coastal environments.
The fabricating prepare employments exactness roll-forming innovation. This strategy shapes metal coils into steady profiles, guaranteeing uniform quality over each board. Your extend benefits from dimensional exactness inside ±0.5mm tolerances.
Thickness alternatives run from 1.5mm to 5.0mm. This assortment lets you coordinate board quality to particular auxiliary prerequisites. Lighter gages work well for insides complement dividers. Heavier choices suit outside applications with wind stack concerns.
Surface coating quality standards
|
Serial Number
|
Item
|
Standard Requirements
|
|
01
|
Appearance Quality
|
No cracks or weld breaks on either side of the aluminum material; no coating peeling or cracking. The appearance is clean and the color is basically consistent, with no obvious scratches. The decorative surface has no obvious indentations, marks, or unevenness. No obvious color changes; the coating has no flow marks, cracks, bubbles, inclusions, or other surface defects.
|
|
02
|
Film Thickness
|
Average film thickness ≥ 50μm, minimum local film thickness ≥ 34μm.
|
|
03
|
Gloss Deviation
|
Gloss range 31.0～33.9, average 32.0
|
|
04
|
Adhesion
|
Cross-cut test, grade 0
|
|
05
|
Hardness
|
≥2H
|
|
06
|
Acid Resistance
|
5% HCl, 24h, no change
|
|
07
|
Abrasion Resistance
|
6.6L/μm
|
|
08
|
Warranty Period
|
≥ 10 years
|
Versatile Design Applications
These aluminum sheet metal wall panels adapt to numerous architectural styles. Roll-forming allows complex shapes including angles, curves, and custom profiles. You can wrap corners seamlessly or follow irregular wall geometries.
Interior applications include accent walls, backsplashes, and feature panels. The industrial aesthetic complements modern design trends. Installation weight stays low at just 1-3 pounds per square foot.
Exterior uses span warehouses, workshops, and residential facades. The interlocking design creates weather-tight assemblies. Thermal movement joints accommodate expansion and contraction cycles.
Professional Installation Support
Our comprehensive benefit bundle incorporates CAD 3D modeling and fabric mechanics reenactment. These devices approve your plan some time recently manufacture starts. Manufacturing plant pre-assembly testing guarantees field establishment continues smoothly.
Detailed development drawings direct your establishment group. On-site specialized bolster is accessible for complex ventures. Our establishment strategy keeps up extend resiliences inside ±0.5mm.
Custom measuring disposes of field cutting and squander. Boards arrive prepared for quick establishment. Standard conveyance timeframes extend from 15-64 days depending on venture complexity.
Quality Certifications and Standards
International certifications validate our manufacturing excellence:
- CE marking for European markets
- UL listing for North American applications
- SASO approval for Middle Eastern projects
- ISO 12944-6 certification for corrosion protection
Each certification demonstrates compliance with regional safety and performance standards. Your project specifications align with local building codes automatically.
Environmental Sustainability
Aluminum offers characteristic recyclability. End-of-life boards hold full fabric esteem through reusing forms. Moo encapsulated vitality amid fabricating diminishes natural impact.
The lightweight plan diminishes basic loads. Littler establishments and surrounding frameworks diminish generally venture fabric utilization. Transportation effectiveness makes strides due to diminished shipping weight.
PVDF coatings contain no overwhelming metals or unstable natural compounds. Indoor discuss quality remains unaffected amid and after establishment.
Contact Us
Ready to transform your next project with premium aluminum sheet metal wall panels? Contact our technical team at [email protected] for detailed specifications, custom quotes, and design assistance tailored to your specific requirements.
