profil aluminium curtain wall
Thickness:1.5-5.0mm
Material:1100, 3003, 5005, 6063, etc
Surface treatment:PVDF/PE
Supply capacity:50000 ㎡/month
Service life:30-year warranty
Minimum Order Quantity (MOQ):30㎡
Color:RAL and other customized colors
Size Customized size
Feature:Durable, easy to install, environmentally friendly, high-quality
Certificate:CE，UL，SASO，ISO 12944-6
Delivery time:15-76 days
Installation Guide:Provide detailed construction drawings
Place of Origin:Guangdong, China
- Product Description
Profil Aluminium Curtain Wall - Premium Architectural Solutions
Transform Your Building's Facade with Expert-Engineered Profil Aluminium Curtain Wall Systems
Looking for a cutting-edge facade solution that combines structural excellence with striking aesthetics? Our profil aluminium curtain wall systems deliver exactly what modern architects demand. These custom-engineered aluminum profiles create distinctive linear patterns while providing unmatched structural integrity. You'll get precision-crafted rails, mullions, and frames that transform ordinary building exteriors into architectural masterpieces. With over 50,000 square meters of monthly production capacity and precision engineering that ensures installation errors stay below 0.5mm, we make your vision reality.
Superior Materials and Engineering Excellence
Our aluminum profiles use premium 6063 alloy, specifically chosen for its exceptional strength-to-weight ratio. You benefit from materials that support substantial loads while maintaining effortless installation processes. The extrusion manufacturing creates consistent dimensions across massive installations, ensuring your facade maintains perfect alignment.
Material options include 1100, 3003, 5005, and 6063 aluminum grades. Thickness ranges from 1.5mm to 5.0mm, giving you flexibility for various structural requirements. Surface treatments feature durable PVDF and PE coatings that resist weathering, UV damage, and corrosion.
Customization That Meets Your Vision
Each extend merits special arrangements. Our item frameworks offer boundless customization conceivable outcomes. You can indicate profile shapes, sizes, dispersing, and introductions to make particular exterior rhythms. Whether you incline toward strong vertical accentuation or exquisite even lines, we fabricate profiles that accomplish your correct plan intent.
Color choices span the total RAL palette furthermore custom definitions. Our progressed powder coating and anodizing forms convey steady wraps up over whole establishments. Surface quality meets the most noteworthy universal measures, with normal film thickness surpassing 50μm and predominant grip properties.
Professional Services and Support
We provide comprehensive project support from initial concept through final installation. Our team creates detailed CAD 3D modeling, performs material mechanics simulations, and conducts factory pre-assembly testing. You receive complete construction drawings and on-site technical guidance throughout installation.
Our quality management includes factory inspections, material testing, and performance validation. Every profil aluminium curtain wall component meets CE, UL, SASO, and ISO 12944-6 certification requirements. This ensures compliance with international building codes and performance standards.
Surface coating quality standards
|
Serial Number
|
Item
|
Standard Requirements
|
|
01
|
Appearance Quality
|
No cracks or weld breaks on either side of the aluminum material; no coating peeling or cracking. The appearance is clean and the color is basically consistent, with no obvious scratches. The decorative surface has no obvious indentations, marks, or unevenness. No obvious color changes; the coating has no flow marks, cracks, bubbles, inclusions, or other surface defects.
|
|
02
|
Film Thickness
|
Average film thickness ≥ 50μm, minimum local film thickness ≥ 34μm.
|
|
03
|
Gloss Deviation
|
Gloss range 31.0～33.9, average 32.0
|
|
04
|
Adhesion
|
Cross-cut test, grade 0
|
|
05
|
Hardness
|
≥2H
|
|
06
|
Acid Resistance
|
5% HCl, 24h, no change
|
|
07
|
Abrasion Resistance
|
6.6L/μm
|
|
08
|
Warranty Period
|
≥ 10 years
|
Applications and Compatibility
Advanced window ornament divider frameworks suit assorted building styles. Corporate central command advantage from clean, proficient aesthetics. Social centers accomplish unmistakable character through inventive profile courses of action. High-rise advancements maximize visual affect whereas keeping up auxiliary efficiency.
Our frameworks coordinated consistently with protects glass units, strong boards, and mixed-media exteriors. Profile dispersing suits insides formats, mechanical frameworks, and lighting necessities. Vitality productivity optimization incorporates warm break integration and condensation administration.
Installation and Maintenance
Professional installation begins with precise measurement and quality control. Our detailed drawings specify connection methods, weatherproofing requirements, and structural attachments. Factory pre-assembly reduces field errors and accelerates construction schedules.
Maintenance requirements stay minimal throughout the 30-year service life. Regular cleaning maintains appearance, while periodic inspections ensure continued performance. Our profil aluminium curtain wall systems resist environmental stresses, reducing long-term maintenance costs.
Ready to elevate your building's architectural presence? Contact our experienced team at [email protected] for detailed project consultation and customized solutions that exceed your expectations.
