aluminum cladding system
Thickness:1.5-5.0mm
Material:1100, 3003, 5005, 6063, etc
Surface treatment:PVDF/PE
Supply capacity:50000 ㎡/month
Service life:30-year warranty
Minimum Order Quantity (MOQ):30㎡
Color:RAL and other customized colors
Size Customized size
Feature:Durable, easy to install, environmentally friendly, high-quality
Certificate:CE，UL，SASO，ISO 12944-6
Delivery time:15-58 days
Installation Guide:Provide detailed construction drawings
Place of Origin:Guangdong, China
- Product Description
Professional Aluminum Cladding System Solutions for Modern Architecture
Are you looking for a reliable exterior building solution that combines durability, aesthetics, and energy efficiency? Our aluminum cladding system represents a comprehensive, engineered approach to modern building exteriors. This turnkey solution integrates aluminum panels, support structures, insulation, and weatherproofing components into one cohesive framework. Designed specifically for architects, contractors, and building owners who demand excellence, our system simplifies construction while delivering superior performance that lasts for decades.
Complete System Components for Superior Performance
Our items incorporate everything you require for a effective establishment. The system comprises of pre-cut aluminum boards customized to your building's correct measurements, disposing of mystery and decreasing squander. Galvanized steel or aluminum rails mount safely to your structure, giving a strong foundation.
Concealed latches guarantee a clean, proficient appearance whereas keeping up basic judgment. High-quality sealants avoid water interruption, ensuring your building's insides. We offer boards in thicknesses extending from 1.5mm to 5.0mm, made from premium materials counting 1100, 3003, 5005, and 6063 aluminum alloys.
Surface coating quality standards
|
Serial Number
|
Item
|
Standard Requirements
|
|
01
|
Appearance Quality
|
No cracks or weld breaks on either side of the aluminum material; no coating peeling or cracking. The appearance is clean and the color is basically consistent, with no obvious scratches. The decorative surface has no obvious indentations, marks, or unevenness. No obvious color changes; the coating has no flow marks, cracks, bubbles, inclusions, or other surface defects.
|
|
02
|
Film Thickness
|
Average film thickness ≥ 50μm, minimum local film thickness ≥ 34μm.
|
|
03
|
Gloss Deviation
|
Gloss range 31.0～33.9, average 32.0
|
|
04
|
Adhesion
|
Cross-cut test, grade 0
|
|
05
|
Hardness
|
≥2H
|
|
06
|
Acid Resistance
|
5% HCl, 24h, no change
|
|
07
|
Abrasion Resistance
|
6.6L/μm
|
|
08
|
Warranty Period
|
≥ 10 years
|
Engineered for Precision and Reliability
What sets our aluminum cladding system apart is the precision engineering behind every component. Our services include CAD 3D modeling and material mechanics simulation, ensuring perfect fit before production begins. Factory pre-assembly testing catches potential issues early, while on-site technical guidance guarantees proper installation.
We maintain project errors at or below 0.5mm - a tolerance that reflects our commitment to excellence. This precision reduces construction time and eliminates costly field modifications.
Comprehensive Color and Finish Options
Choose from RAL standard colors or request completely customized finishes to match your architectural vision. Our coating quality standards exceed industry requirements, with average film thickness of 50μm minimum and local thickness never below 34μm.
The gloss consistency ranges from 31.0 to 33.9, averaging 32.0 for uniform appearance across large surfaces. Cross-cut adhesion testing achieves grade 0, while hardness ratings exceed 2H for superior durability.
Proven Applications and Performance
Large-scale commercial ventures depend on our frameworks for their basic outside prerequisites. Airplane terminals, shopping centers, and corporate central station select our arrangements since framework unwavering quality is non-negotiable in these applications.
The warm break innovation anticipates warm exchange, essentially progressing vitality productivity. Extension joints oblige normal building development, whereas fire-resistant components meet the strictest security codes.
Installation Support and Technical Guidance
We give nitty gritty development drawings and comprehensive establishment guides with each arrange. Our group offers on-site specialized back to guarantee your venture meets our demanding standards.
Delivery times extend from 15 to 58 days depending on customization necessities and extend scope. This solid timeline makes a difference you keep up development plans without compromise.
Quality Certifications and Standards
Our product carries CE, UL, SASO, and ISO 12944-6 certifications, validating performance across international markets. These certifications represent rigorous testing for wind resistance, water penetration, and thermal performance.
Acid resistance testing with 5% HCl for 24 hours shows no changes, while abrasion resistance reaches 6.6L/μm. These specifications ensure your investment maintains its appearance and performance for the full warranty period.
Environmental Responsibility and Sustainability
Sustainability drives our material innovation and manufacturing processes. Aluminum's recyclability makes our systems an environmentally responsible choice that supports green building initiatives without compromising performance or aesthetics.
Our scenario-based solutions approach means you receive exactly what your project requires - nothing more, nothing less. This reduces waste and optimizes resource utilization.
Ready to discuss your next project? Our aluminum cladding system experts are standing by to help you achieve your architectural goals. Contact us at [email protected] to explore how our engineered solutions can transform your building's exterior while delivering lasting value and performance.
